Installation and operating manual
(PVI-3.8/4.6-I-OUTD Rev.: 1.5)
3.4.3

AC and DC wire selection

The following tables will help the installer to select AC and DC wires
DC input wiring
Ground
AC output wiring
Main ground
DC input wiring
Ground
AC output wiring
Main ground
PVI-3.8-I-OUTD
PVI-3.8-I-OUTD
PVI-3.8-I-OUTD
PVI-3.8-I-OUTD
PVI-3.8-I-OUTD
PVI-4.6-I-OUTD
PVI-4.6-I-OUTD
PVI-4.6-I-OUTD
PVI-4.6-I-OUTD
PVI-4.6-I-OUTD
AWG 167°F
(75°C)
8-6
4
8-6
6
AWG 167°F
(75°C)
8-6
4
8-6
6
Page 28 of 95
AWG 194°F
(90°C)
10-6
4
10-6
6
AWG 194°F
(90°C)
10-6
4
8-6
6
