Settings; Address - Power One Aurora PVI-3.8-I-OUTD-S Installationshandbuch Und Benutzerhandbuch

Installation and operating manual
(PVI-3.8/4.6-I-OUTD Rev.: 1.5)
5.5.6

Settings

If you select SETTINGS from the Main menu (chapter 5.5.4), the first screen will
appear on the display, concerning the password:
The default password is 0000. It can be changed using the display keys in the usual
way:
Use ENTER to scroll from one figure to another (from left to right)
Use ESC to return to the previous figure (from right to left)
Press ESC repeatedly to return to the previous menus, as described in
chapt.5.5.3
Use DOWN to scroll through the numbers in descending order (from 9 to 0)
Use UP to scroll through the numbers in ascending order (from 0 to 9)
After having entered the correct password, press ENTER to access to the different
information saved in this section:
The display only shows 2 lines, so to scroll through the entries and access each of the
submenus, use the UP and DOWN buttons.
Password
****

Address

Display settings
Service
New Password
Currency
Date/Time
Language
Vstart
Autotests
Alarm
Remote control
UV Prot.time
MPPT
Alarm Message
Password
0000
Page 66 of 95
