8 MENU STRUCTURE

Menu
Delete Last Reading
Calibration
Setup
About
Reset
Emergency Light
Display
Clear Statistics
Setup Display
Display Information

9 UPGRADING YOUR GAUGE

Gauge firmware can be upgraded to the latest version by the user via
®
ElcoMaster , as it becomes available. ElcoMaster will inform the user
of any updates when the gauge is connected to the PC with an
internet connection.
10 SPARES & ACCESSORIES
10.1 TRANSDUCERS
Each gauge is supplied complete with 5MHz 1/4" Potted Right Angle
Dual Element Transducer. Other transducers are available to order as
accessories - see Table 1 'Transducers' on page en-9.
Transducers are potted - the transducer cable is permanently fixed to
the transducer head - right angle, dual element, 'intelligent'
transducers. When connected, the transducer frequency and diameter
will be automatically identified by the gauge.
When choosing a transducer, the frequency, diameter and material
under test should be considered. As the Elcometer 204 is pre-
calibrated for steel, only transducers suitable for measuring on steel
should be used with this gauge.
Details of the transducer connected can be viewed at any time via
Menu/About/Transducer Information.
www.elcometer.com
Calibration
Zero Set
Setup
Units
Language
Beep Volume
Screen Settings
Gauge Auto Off
About
Gauge Information
Transducer Information
Contact
Legal
Setup Display
Top Display
Bottom Display
Units
mm ○
○
Inch
Screen Settings
Screen Brightness
Screen Timeout
Opening Screen ○
Legal
Legal Notices
Regulatory
Top Display
None
○
Statistics
○
Readings ○
Bottom Display
None ○
Statistics ○
Readings ○
®
R
Regulatory
