Specifi cations (continued)
Monitoring
Monitoring Control function which enables monitoring of displayed audio signals.
Functions:
Outputs:
Deembedded out
Output routing for deembedded audio signals.
Functions:
Outputs:
Timecode Reader
Decoding, display and use of external or SDI Timecode signals.
Display:
Mode:
Input:
Colors:
EN-78 7 | Specifi cations
Monitor level control with onscreen level fader (can be
calibrated), DIM, Mute, Solo, internal Downmix for multi-
channel monitoring, audio output of monitoring signals via
Line Out and Phones connector.
• Analog 2-ch. Stereo (unbal.), 2 x RCA
• Analog 2-ch. Stereo headphone (unbal.), 3.5 mm jack
Deembedded output of up to 16 audio channels via 8 x
AES3 outputs
8 x AES3 (bal.), 25-pin Sub-D connector
numerical display of
• LTC (from analog source via Aux In)
• VITC (via SDI data stream via 3G-SDI In)
LTC, VITC; instrument selectable when creating a Non-
Audio group
one analog or SDI channel selectable
selectable, 32 colors
