Specifi cations (continued)
PPM/True Peak Display
General
Input sources:
Peakmeter:
Display:
Functions:
Digital Peakmeter
Word width:
Digital scales:
Headroom/Headroom Ref: adjustable, 1 dB steps from 0 to –20 dB
Operation fi eld:
Integration time (Attack): acc. to corresponding standard or selectable:
Gain:
High-pass fi lter:
Peak hold indicator:
Over indicator hold time: 1 s or manual
Manual | TM3-3GS
digital (3G/HD/SD-SDI)
2-channel Stereo up to 8 channels
• Peak level
• Peak hold (selectable color)
• Numerical value of the display
• Gain (+20 dB, +40 dB acc. to standard)
• Peak hold on/off
• Memory
• Reset
24 bit
• TP60: +3 .. –60 dB
• TP20: +3 .. –20 dB
• Dig60: 0 .. –60 dB
• Dig20: 0 .. –20 dB
• Dig0: +18 .. 0 dB
• Dig18: +18 .. –18 dB
• Dig40: +20 .. –40 dB
• ARD9: +9 .. –60 dB
• DIN5: +5 .. -50 dB,
• DIN10: +10 .. -50 dB,
• Nordic: +12 .. -42 dB,
• BR IIa: 7 .. 1 (British),
• BR IIb: +12 .. -12 dB (British),
• Zoom10: +10 .. –10,
• Zoom1: +1 .. –1,
adjustable, 1 dB steps from 0 to –20 dB
Sample, 20 ms, 10 ms, 1 ms, 0.1 ms
+20 dB, +40 dB (acc. to standard)
Off, 5 Hz, 10 Hz, 20 Hz
1 s, 2 s, 4 s, 10 s, 20 s, 30 s, manual reset or off
7 | Specifi cations EN-73
