5.2 | Loudness Sum

Tolerance
range
Momentary
bargraph M
Example: Loudness Sum instrument in EBU mode shows Momentary bargraph M
and Shortterm bargraph S. The Integrated bargraph I is hidden.
The Loudness Sum instrument shows the combined total loudness
consisting of the summed single channels of a signal. This instrument
shows up to three bar graphs representing measurements with individual
integration time constants. For stereo sources, the L and R channels are
summed. For 5.1 sources, the fi ve main channels (5.0) are used for the
measurement.
Manual | TM3-3GS
Scale mark for
Target Level
Shortterm
bargraph S
5 | Instruments | 5.2 | Loudness Sum
