Specifi cations (continued)
Over indicator PPM
- Threshold:
- Attack time:
- Word width:
Over indicator True Peak
- Threshold:
SDI Status Monitor
Display:
Global Keyboard
Loudness and SPL Display
EBU R128 Loudness Mode
ITU-R BS.1771 Loudness Mode
ATSC A/85 Loudness Mode
ARIB Loudness Mode
OP-59 Loudness Mode
AGCOM Loudness Mode
CALM Loudness Mode
EN-74 7 | Specifi cations
Full Scale, Full Scale -1LSB, Full Scale -2LSB, –0.1 dBFS,
–0.5 dBFS, –1 dBFS, –2 dBFS, –3 dBFS
1 to 15 samples
16 to 24 bit, selectable
adjustable
• channel data are displayed as plain text, hex
or binary
• Channel selectable
• Audio bit activity
• Hardware status
The Global Keyboard is used for control of defi ned
functions in multiple instruments, and for preset recall. It
also allows the external control with the integrated GP IO
interface.
