Specifi cations (continued)
Digital Inputs
Inputs:
Outputs:
Functions:
Deembedding:
SDI formats:
- SD:
- HD:
- 3G:
EN-72
7 | Specifi cations
• Loudness Test Time Control
• Loudness Range instrument (LRA)
• Loudness Chart instrument
• SPL meter
• Stereo Correlator
• Dialnorm (w/o speech intelligence)
• SDI status monitor
• Numerical displays
• 16-ch. 3G/HD/SD-SDI deembedder
• Routing of deembedded audio signals to AES3 outputs
• Monitoring Controller with onscreen level fader
• Moving Coil instruments
1 x 3G-SDI In (unbalanced), BNC-F
1 x 3G-SDI Through (unbalanced), BNC-F, input signals
are active looped through without processing
• Detection of validity of the applied SDI signal
• Detection of frequency (SD/HD/3G)
• Detection of contained format
• Detection of validity of the contained and applied audio
groups and deembedding
• Single link (SD/HD/3G): max. 4 audio groups with 4
audio channels each
• Dual link (3G): max. 8 audio groups with 4 audio
channels each
• 3G: max. 4 audio groups with 4 audio ch. each
525i, 625i
720p (23.98, 24, 25, 29.97, 30, 50, 59.94, 60 Hz)
1035i (59.94, 60 Hz)
1080i (50, 59.94, 60 Hz)
1080p (23.98, 24, 25, 29.97, 30 Hz)
1080SF (23.98, 24, 25, 29.97 Hz)
1080p (23.98, 24, 25, 29.97, 30, 50, 59.94, 60 Hz)
Manual | TM3-3GS
