With this function, any displayed audio signals depending on the used
format can be routed directly or as a downmix to the Line Out L/R (RCA)
resp. Phones (3.5 mm jack) analog outputs for monitoring. The level fader
positioned on the screen allows the volume adjustment. Additionally, Dim
and Mute functions keys can be displayed to dim or to mute the volume
just by a fi ngertip. These keys may have switching function (on/off) or
momentary function for temporary activation by holding the key.
Factory presets using the Monitoring instrument (without Dim and Mute
keys):
• 5.1 SDI ATSC MON
• 5.1 SDI EBU MON
• 5.1+2CH SDI ATSC MON
• 5.1+2CH SDI EBU MON
