7 | Specifi cations
System
General
Power requirements:
Current drain:
Display:
Connectors:
Dimensions (W x H x D): Display unit:
Weight:
Operating temperature:
Functions
Manual | TM3-3GS
+24 V DC (external 2 A max. overcurrent protective device
shall be installed!)
160 mA nominal, power-up current is much higher
4.3'' touch screen (272 x 480 pixel)
• 1 x 4-pin locking low voltage connector type Binder
710 (DC)
• 1 x USB Mini-B; USB 2.0 Full Speed connectors for
data exchange between Device Confi gurator computer
software Devicer DC1 and TM3-3G
• 1 x GPIO (RJ-12-6P6C) for defi ned functions or preset
recall
• 2 x BNC-F, 3G-SDI In, Through (unbal., digital)
• 2 x RCA-F, Line Out (unbal., analog)
• 1 x RCA-F, Aux In (unbal., analog)
• 1 x 25-pin Sub-D-F, Bal.Out (bal., 8 x AES3 out)
• 1 x 3.5 mm jack, Phones (unbal., analog)
3G-SDI Interface box: 146 x 29 x 85 mm
Display unit approx. 320 g, interface box approx. 460 g,
w/o mains adapter
+5° to +40° C
• Instruments can be scaled and freely positioned
• PPM up to 8 channels
• Loudness-Meter: ITU-R BS.1770-4/1771-1, EBU
R128, ATSC A/85, ARIB, OP-59, AGCOM, CALM,
custom mode
82.5 x 138 x 50 mm (table-top unit)
