ECOFOREST ecoGEO Basic series Technisches Servicehandbuch Seite 48

ecoGEO B2 / ecoGEO B4 / ecoGEO C2 / ecoGEO C4
12
Flow Rate source = Flow rate cooling = 2000 l/h
11
Flow Rate source = Flow rate cooling = 2500 l/h
10
9
8
7
6
5
4
3
2
1
0
0 1 2 3 4 5
DT = T4 - T2 (ºC)
48
Technisches Servicehandbuch ecoGEO
T4 T1
T3 T2
6 7 8 9 10
