Preparation For Operation - GRAPHITE 58G060 Betriebsanleitung

1 2
1.
Read instruction manual, observe warnings and safety conditions therein.
2.
Device with class II insulation.
3.
Use personal protection measures (protective goggles, earmuff protectors, anti-dust mask)
4.
Disconnect the power cord before starting maintenance or operation.
5.
Protect against rain.
6.
Keep the tool away from children.
CONSTRUCTION AND USE
Jigsaw is a hand-operated power tool with insulation class II. It is driven by a single-phase commutator
motor. This type of power tools is widely used for cutting wood, wood-like materials, plastics and metals.
Range of use covers repair and building works, and any work from the range of individual, amateur activi-
ties (tinkering).
Use the power tool according to the manufacturer's instructions only.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the drawing pages of this manual.
1.
Wheel for operation speed control
2.
Switch button
3.
Switch lock button
4.
Dust outlet
5.
Footplate
6.
Wheel for pendulum action setting
* Differences may appear between the product and drawing
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY/SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Hex key
2. Dust extraction stub pipe
3. Transport case
BLADE INSTALLATION
Disconnect the power tool from power supply.
Use the hex key to loosen screws that fix the blade shaft (fig. A).
Slide blade into clamp, push to the limit
3 4
- 1 pce
- 1 pce
- 1 pce

PREPARATION FOR OPERATION

14
5 6
