Scale allows for setting the footplate to angles: 0
immediately after adjustment has been made.
CUTTING
Lower the blade guard.
Switch on the jigsaw and wait until it reaches its top speed.
Press the jigsaw footplate (5) against material to be processed.
Move the jigsaw slowly along previously set cutting line.
Press the jigsaw very gently when making curved cuttings.
RECOMMENDATIONS FOR PROPER JIGSAW USE
Cut at a uniform rate, pay attention to avoid overloading the power tool. Excessive pressure applied on the
blade will suppress pendulum action, it will affect cutting efficiency unfavourably. Decrease or switch off
the pendulum action completely when cutting along gently curved line.
If the jigsaw footplate does not move on the processed material, but is lifted instead, there is a dan-
ger of breaking the blade.
METAL CUTTING / TYPES OF BLADES
Use appropriate blades with more teeth for metal cutting.
For metal cutting use appropriate lubricant (e.g. oil for cutting). Metal cutting without lubrication leads to
rapid wear of blade. The below table gives the best choices for blade type:
Teeth per inch
24
14
9
Use only appropriate and sharp blades.
Do not use blades with damaged shank.
Use appropriate blade types.
Unplug the power cord from mains socket before commencing any activities related to installation,
adjustment, repair or maintenance.
Cleaning the device after each use is recommended.
Do not use water or any other liquid for cleaning.
Clean the tool with a dry cloth or blow with compressed air at low pressure.
Do not use any cleaning agents or solvents, they may damage plastic parts.
Clean ventilation holes in the motor casing regularly to prevent device overheating.
Regular lubrication of guiding roller is recommended. A drop of oil applied in this spot will prolong
lifetime of the roller.
In case of power cord damage replace it with a cord with the same specification. Entrust the repair to
a qualified specialist or return the tool to a service point.
In case of excessive commutator sparking, have the technical condition of carbon brushes of the
motor checked by a qualified person.
Always store the tool in a dry place, beyond reach of children.
REPLACEMENT OF CARBON BRUSHES
Immediately replace worn out (shorter than 5 mm), burnt or cracked motor carbon brushes. Always
replace both carbon brushes at a time.
Entrust replacement of carbon brushes only to a qualified person. Only original parts should be
used.
All defects should be repaired by service workshop authorized by the manufacturer.
o , 15 o , 30
Length
Soft steel, non-ferrous metals
80 mm Non-ferrous metals, plastics
Wood, plywood:

OPERATION AND MAINTENANCE

16
o or 45 o (right or left). Put the hex key in its place
Application range
