DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the drawing pages of this manual.
1. SDS-Max chuck
2. Fixing sleeve
3. Additional handle
4. Locking knob for additional handle
5. Operation mode switch
6. Switch lock button
7. Switch
8. Wheel for rotational speed control
9. Voltage indicator
10. Carbon brushes wear indicator
11. Additional handle
* Differences may appear between the product and drawing.
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY/SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Chisels
2. Drills
3. Additional handle
4. Additional handle
5. Dust cover
6. Grease container
7. Transport case
INSTALLATION OF ADDITIONAL HANDLE
Due to safety issues, always use additional handle (3) when operating the demolition hammer. It can
be fixed in any position from the range of 360
Disconnect the power tool from power supply.
● Slide the collar and additional handle (3) over cylindrical part of the demolition hammer body.
● Install connecting screw with supports.
● Join the clamping wheel of the additional handle (
● Turn the handle for the position that is most comfortable for the work performed.
● Tighten the locking knob for additional handle (
INSTALLATION OF ADDITIONAL HANDLE
Additional handle (11) can be installed in one of the holes on the hammer body.
INSTALLATION AND REPLACEMENT OF WORKING TOOLS
The demolition hammer is designed to operate with working tools with SDS Max shanks. Prior to operation
clean the chuck and working tools. Apply thin layer of grease onto shank of the working tool.
- 1 pce
- 1 pce
- 1 pce
- 1 pce
- 1 pce
- 1 pce
- 1 pce

PREPARATION FOR OPERATION

O
.
4) and the screw (fig. A).
4).
