Unite TH – Handheld Transmitter
4.6 Use as a "Sub-Master"
The Unite TH handheld transmitter can be configured in a
virtual device mode ("Sub-Master"). This allows up to two
additional speakers to be integrated into a device group. You
will find examples for applications in the download area of the
landing page: https://www.beyerdynamic.com/unite at Info
materials/UNITE-USE-CASES
In the "Sub-Master" mode, the transmitter can set up an
exclusive connection to a "Master" device. In one group a
maximum of two "Sub-Masters" can be active. The connection
between a "Sub-Master" and a "Master" device is technically
the same as the connection between a Unite RP-T with
activated "Talkback" function and a "Master". The difference is
that the connection between a Unite RP-T and a "Master" is
temporary while the connection between a "Sub-Master" and
a "Master" is permanent. In this case the audio channel is
permanently open, but it can be muted by pressing the "Mute"
button on the "Sub-Master". In addition there are of course still
possibilities to connect external audio sources to the "Sub-
Master". All audio signals of the "Sub-Master" are distributed
via the "Master" (Broadcast) and can be routed to the "Master".
These options can be found in the "Master" menu at "Talkback"
"Audio Routing".
Examples of up to 3 open microphones in the following
device combinations:
- 1x "Master" + 2x "Sub-Master"
- 1x "Master" + 2x RP-T (Talkback )
- 1x "Master" + 1x "Sub-Master" + 1x RP-T (Talkback)
4.6.1 How to configure a "Sub-Master"
In order to configure the Unite TH transmitter as a "Sub-
Master", proceed as described below:
• Use the On/Off and menu button
"System" "Device Mode".
• Select the "Sub-Master" option.
• Confirm the selected option with the On/Off and menu
button .
• Restart the transmitter by pressing the On/Off and menu
button .
• The transmitter reconfigures itself. This can take 1 - 2 minutes.
• You can reconfigure the device as "Master" at any time.
Note: When you configure a transmitter as a "Sub-Master" a
factory setting for the "Sub-Master" will be automatically
activated. This sets the value for the "ALC" function to "Far"
and for the "Noise Canceller" function to "low". This is also the
factory setting for the configuration as "Master".
to access the menu
