Unite TH – Handheld Transmitter
There is an active, bidirectional talkback connection
(Full-Duplex connection) between:
– a "Master" and a Unite RP-T receiver
– a "Master" and a "Sub-Master"
The "hi" symbol is only displayed on the connected
devices during an active talkback connection.
The other devices of a group display a highlighted "S" during
an active talkback connection between two devices.
Display of remaining battery capacity
4.

General operation

• Important: Before using the handheld transmitter for the
first time, you must charge the built-in battery. Please use an
appropriate Unite charger or the USB connection.
• Switch on the transmitter by pressing the on-off button
• In order to establish an audio connection between a
transmitter and one or more receivers, all devices must be
paired together. See chapter 5.
• All devices are supplied with the group ID 256 and fixed
audio encryption allowing quick and easy initial use. This
allows a fast and easy first use, since there is no pairing
required for the open group ID range between 150 and 256.
• The transmitter will only transmit the audio signal on a
channel with a predefined channel name. If there are
several transmitters in the group ID between 150 and 256, the
channel for the respective transmitter can be selected on
the receiver.
4.1

Maintenance

• Protect the handheld transmitter from humidity, knocks and
shock. Avoid dropping the transmitter at all times.
• For cleaning the plastic surface of the handheld transmitter
use a soft cloth moistened with a solvent-free plastic
cleaner.
• As soon as your microphone
sounds dull, you should clean
the integrated pop shield:
– Unscrew the microphone
grille anti-clockwise.
– Pull out the foam pop
shield, if necessary use
tweezers.
Unscrew microphone grille
Pull out the pop shield
11
.
