10
Coloured ring, replaceable
Type plate
Charging contacts
The built-in battery is charged via the charging contacts
when the device is inserted into the charger. Make sure to
insert the device fully into the charging slot so that the
charging contacts have proper contact.
USB port, Type C
You can use this connector to charge the integrated battery
via a USB power adapter. Furthermore, you can connect the
handheld transmitter to the USB Type C port on a Unite
charger to charge it or to pair it with other devices.
3.2 Display
The main screen (below) is displayed when the handheld
transmitter is switched on and ready for operation.
¸
M
¹
µ Display of all active speakers
M = "Master"
st
S = 1 "Sub-Master" or 1
nd
S = 2 "Sub-Master" or 2
(the highlighted display shows if the "Master",
st
1 "Sub-Master" or 2
¸ An underline displays if the device has been configured as
a "Master" or "Sub-Master". .
Underlined "M" = "Master"
Underlined "S" = "Sub-Master"
¹ Current channel name
Bluetooth® status
(various symbols; depending on the status)
Bluetooth activated
Bluetooth connected
Display of active or muted microphone:
Microphone muted
Microphone active
µ
S S
UNITE
st
nd
"Sub-Master" is active)
Unite TH – Handheld Transmitter
80
%
speaker (Unite RP-T)
nd
speaker (Unite RP-T)
