4.6.2 How to connect a "Sub-Master" to a "Master"
In order to connect a "Sub-Master" to a "Master", you have to
perform a channel search. Please proceed as described
below:
• Press the p or q symbol of the multifunction button
start the dynamic channel search.
• The basic conditions to establish a connection must be
guaranteed (refer to chapter "Pairing information").
Alternatively, you can transmit the pairing information via a
charger. As a "Sub-Master", the transmitter will receive the
channel name, group ID and audio encryption key from the
charger like a Unite RP or RP-T.
4.7 How to use with a Unite AP4 access point
In conjunction with a Unite AP4 access point the Unite TH can
be used as a wireless microphone. In order to establish a
connection to a Unite AP4, the Unite TH must be configured as
"AP4 Mic (Sub-Master)" via the menu. This mode is technically
equivalent to a "Sub-Master", which can establish an exclusive
connection to a "Master" (Unite AP4).
4.7.1 How to configure as "AP4 Mic (Sub-Master)"
• In order to configure the Unite TH in the "Sub-Master" mode,
select in the menu "System"
(Sub-Master)".
• Confirm the selected option with the On/Off and menu
button .
• Restart the transmitter by pressing the On/Off and menu
button .
• The transmitter reconfigures itself. This can take 1 - 2 minutes.
• You can reconfigure the device as "Master" at any time.
4.7.2 How to connect to a Unite AP4 Master
• In order to use the Unite TH as a wireless microphone with a
Unite AP4, you must perform a channel search.
• Press the q or p symbol of the function button on the
Unite TH to start the dynamic channel search. The basic
conditions to establish a connection must be guaranteed
(refer to chapter "Pairing information").
• The second way to establish a connection between the
Unite TH and Unite AP4 is to use the Unite Manager PC
software for pairing. Please refer to the Unite Manager PC
software manual.
Unite TH – Handheld Transmitter
"Device Mode"
and
"AP4 Mic
