Unite TH – Handheld Transmitter
6.

Technical specifications

DECT RF frequency range . . . . . 1880 - 1930 MHz,
DECT transmission power . . . . . . up to 250 mW (peak),
DECT operating range . . . . . . . . . up to 300 m outside
Operating mode. . . . . . . . . . . . . . . Broadcast and/or
Encryption . . . . . . . . . . . . . . . . . . . . . AES-256 bit encryption
Display . . . . . . . . . . . . . . . . . . . . . . . . monochrome white OLED
DECT audio bandwidth
Low quality (SD) . . . . . . . . . . . . . . 50 Hz - 7 kHz (-3 dB)
High quality (HD) . . . . . . . . . . . . . 50 Hz - 14 kHz (-3 dB)
Simultaneously
active microphones . . . . . . . . . . . up to 3 open microphones
Side-tone and
microphone gain . . . . . . . . . . . . . . individually adjustable
Microphone capsule
Transducer type . . . . . . . . . . . . . Condenser
Operating principle . . . . . . . . . . Pressure gradient
Polar pattern. . . . . . . . . . . . . . . . . Cardioid
Frequency response
in HD mode:
Close miking . . . . . . . . . . . . . . . . . 40 - 15,000 Hz
Distant miking
(measured at 1 m) . . . . . . . . . . . . 200 - 15,000 Hz
Max. SPL at 1 kHz . . . . . . . . . . . . . 120 dB SPL
Bluetooth® . . . . . . . . . . . . . . . . . . . . . V4.2
USB Type C connector . . . . . . . . . only for standard USB power
depending on the country
depending on the country
(line of sight);
the actual operating
range depends upon the
RF output settings, the
surroundings, the signal
absorption, signal
reflection and signal
interference
full-duplex on all routes
display with high contrast
with the following device
combinations:
1x "Master" + 2x "Sub-Master"
1x "Master "+ 2x RP-T (Talkback)
1x "Master" + 1x "Sub-Master" +
1x RP-T (Talkback)
(back electret)
(HFP - Hands-Free-Profile,
A2DP - Audio streaming)
adapters (5 V)
power consumption
max. 500 mA
