1
Quick Setup Guide

1.2 Jumpers

1.2.1 Clear CMOS Date - JP1
1.2.2 Jumper Settings for Selecting the PS/2 Power
1 2 3
1-2 On: VCC
power
1 2 3
2-3 On:
5V_DUL power
(default)
Note:
If you wish to use the Wake-On-PS/2 Keyboard function, make sure this
jumper is set to "2-3 On". "PS2KB Wakeup Select" ("IRQ/Event Activity
Detect" field) in the Power Management submenu of the BIOS must be set
10
accordingly.
Clear CMOS
1 2 3
PS/2 power select
(JP2)
1
2
3
1-2 On: Normal
(default)
1
2
1
3
2
2-3 On:
3
Clear CMOS Data
(JP1)
