1.2 Jumpers

1.2.1 Clear CMOS Data - JP8
1.2.2 Onboard Audio Codec - JP1 and JP2
1 2 3
Audio codec
settings (JP1 & JP2)
If you are not using the onboard audio codec, set pins 2 and 3 to On
(Disabled) and set the "VIA-3058 AC97 Audio" ("VIA OnChip PCI
Device" field) in the Integrated Peripherals submenu of the BIOS to
Disabled.
manuals search engine
Quick Setup Guide
1
1-2 On:
2
Normal (default)
3
Clear
1
CMOS 1
2
(JP8)
3
2-3 On:
2
Clear CMOS Data
3
1 2 3
1-2 On:
Enable the Onboard
JP1
Audio Codec
JP2
(default)
1 2 3
2-3 On:
JP1
Disable the Onboard
Audio Codec
JP2
JP1
JP2
1
7
