DFI PM12-EC Benutzerhandbuch Seite 13

1.3.4 Universal Serial Bus Ports
USB 2
USB 1
11
1
USB 3 and USB 4
(J13)
Additional USB Ports (USB 3 and USB 4)
Function
Pin
1
2
3 UP5+
4 Ground
5
The Wake-On-USB Keyboard/Mouse function, when enabled, allows a USB
keyboard/Mouse to wake up a system that is in the S3 (STR - Suspend
To RAM) state.
CN1
15
5
Pin
Function
VCC 6
VCC
UP5- 7
UP6-
8
UP6+
9 Ground
Key 10
N. C.
Quick Setup Guide
11 15
1 5
Pin
Function
11
Ground
12
Ground
13
UP5+
14 UP5-
15
VCC
1
13
