are different from those indicated as there is
a risk that the base could become detached
from the vehicle's seat.
• Make sure that the vehicle's three-point seat
belt for attaching the base and the car seat
is always taut and not twisted. It should be
replaced if it undergoes excessive stress in an
accident.
• If you are unsure of anything, contact the
manufacturer or the retailer of this car seat.
• Do not remove the stickers; this could mean
that the product no longer conforms with the
standards.
• Do not use this car seat base if it is broken or
has missing parts, if it is second-hand or if it
has undergone violent stress in an accident,
as it may have extremely dangerous structural
damage.
• Do not modify the product.
• For any repairs, replacement parts or
information on the product, contact the post-
sales assistance service. Details can be found
on the last page of this manual.
• Do not use this car seat base after five years
from the production date indicated on
the structure. Due to natural ageing of the
materials, it may no longer conform to the
standards.
instructions for use in car
1• Place the base for the child car seat on the seat
of the vehicle. Since not all vehicle seats slope
at the same angle, the height-adjustable base
will allow you to keep the child car seat in the
correct position, parallel to the ground.
• The position of the base is correct when the
bubble on the gauge is completely visible.
• To adjust the base, use one hand to turn knob
A, and the other hand to push down on point
B to simulate the child's weight. Adjust the
base so that the bubble is completely visible in
the gauge.
2• Thread the vehicle's seat belt through the two
side guides of the base, making sure that it
is taut, and buckle the vehicle's seat belt, as
shown in the figure.
3• If your vehicle is equipped with a seat belt
with a free-sliding buckle (like most modern
vehicles), you must attach a Surefix Clip to
BaseAdjustable_FI000701I64.indd 8 BaseAdjustable_FI000701I64.indd 8
it. Using a Surefix Clip guarantees correct
attachment of the child car seat to the base.
• Remove the Surefix Clip from its housing, as
shown in the figure.
• Grab the vehicle shoulder strap (the free strap)
just above the buckle, and hold it taut while
slipping the Surefix Clip onto the free strap, as
shown in the figure. The Surefix Clip must hold
the strap taut. (Once the Surefix Clip has been
mounted correctly, it can be left on the vehicle
seat belt to make it easier to fasten the base
each time).
• After mounting the Surefix Clip, check the
tilt of the base again. If the bubble is not
completely visible in the gauge, turn the knob
again to tighten the belt.
• The base is ready for fastening the child car
seat to it.
4• Place your child in the child car seat, and
fasten the safety belt.
• The car seat must be positioned backwards, in
relation to the direction of the vehicle.
• Fasten the car seat to the base, pressing with
both hands until it clicks into place.
5• Take the vehicle's seat belt again and pass it
behind the back-rest of the child's car seat,
placing it in the rear guide, as shown in the
figure.
6• In the car the handle must be completely
lowered forwards, near to the backrest of the
vehicle's seat, as shown in the figure. Push the
handle forwards, making sure that it clicks.
Check that the belt is taut and locked so that it
is safe.
7• To release the child's car seat from the base:
remove the vehicle's safety belt from the guide
on the back of the child's car seat, move the
handle to the transport position, lift the lever
on the backrest up and at the same time
lift the child's car seat. The base can be left
attached in the car, ready for use.

cleaning and maintenance

• This product requires a small amount of
maintenance. Cleaning and maintenance must
only be carried out by adults.
• Clean the plastic parts periodically with a
damp cloth. Do not use solvents or other
similar products.
