GB
Instructions & Warnings
• This sprayer is intended for use with water-based solutions of:
insecticides, fungicides, weedkillers & fertilizers.
• Always follow the chemical suppliers instructions, as well as
the instructions supplied with this sprayer.
• Check with the chemical manufacturer that their product can
be applied using a sprayer.
• Nitric acid, acetic acid and propionic acid must only be used in a
concentration of up to 10%, phosphoric and sulphuric acid in a
concentration of up to 30%, and potassium hydroxide and
caustic soda in a concentration of up to 20%.
• If other products are to be used, ensure they will not be
harmful to the sprayer, people or the environment.
• Upon request, Hozelock will provide you with a list of
materials used in the sprayer's components.
NOT SUITABLE FOR:
• Combustible liquids with a flashpoint below 55° C
• Acids and lyes (for exceptions see above)
• Wetting Agents (tensides)
• Viscous or sticky liquids or liquids that form residues (dyes,
greases)
• Liquid with temperatures above 30° C
Always wear protective clothing, goggles, face mask and
gloves.
Avoid inhaling spray mist.
Avoid skin contact with chemicals.
Always work in a well ventilated area.
Take care to protect children, pets & fish from exposure to
chemicals.
Always wash hands thoroughly after use & especially before
eating.
Always wash any contaminated clothing.
Seek medical attention if spray gets in your eyes or you
develop any symptoms after spraying.
Do not spray near food or food preparation areas.When
spraying crops, pay particular attention to the chemical
manufacturers advice on time before crops can be eaten.
Do not spray any solvent e.g. White spirit.
Spray only thin watery solutions; thicker mixtures will clog
the nozzle.
Powdered chemicals can be sprayed successfully if they are
completely soluble in water. If they are not, or the solution
tends to settle, spraying can still be successful if the mixture
is continually agitated.
If the material to be sprayed contains sediment, strain the
liquid into the sprayer bottle.
Winter Use – drain liquid from all parts and prevent damage
from freezing.
Annual maintenance – At least once per year thoroughly
clean the whole sprayer and apply silicone grease to all
moving parts & seals. Test with water, and if any washer or
seal has perished it must be replaced.
• Before carrying out any maintenance on this sprayer it is
essential to depressurise the bottle.
A
This sprayer is made from many different types of plastic,
and although the liquid you wish to spray may be packed in
plastic, this does not guarantee it will not damage the sprayer.
If you have any doubt about compatibility contact Hozelock
consumer services.
Notes
B
When filling the sprayer ensure that the maximum fill level is
not exceeded.
C
Ensure that the pump is screwed into the bottle tightly.
D
If the sprayer has been used with chemicals, discard safely any
unused solution after use.
E
Fill sprayer with warm water (not hot),
re-assemble the sprayer and spray some of the contents.
Repeat; check that the nozzle is free from sediment.
If necessary repeat the process until the sprayer is clean.
NB : Do not use detergent.
F
The pump O-ring should be lubricated to allow the sprayer to
pump air efficiently. Apply silicone grease regularly, to the
pump O-Ring (A).
G
The nozzle cap & swirl grooves (B) should be kept clean and
free of obstruction. The O-ring should be lubricated to allow
the spray pattern to be easily changed. Apply silicone grease
regularly, to the nozzle O-Ring (C).
H
Keep the trigger clean and free from build up of sediment and
chemicals by regularly flushing after use.
• Winter Use – drain liquid from all parts and prevent damage
from freezing.
Maintenance
• Annual maintenance – At least once per year thoroughly clean
the whole sprayer and apply silicone grease to all moving parts
& seals. Test with water, and if any washer or seal has perished
it must be replaced.
• Always use eye protection when replacing valves, seals or
springs
Guarantee
• Hozelock guarantees this sprayer against any defect arising
from faulty materials or workmanship for a period of 2 years
from the date of purchase, provided that it has only been used
in accordance with these instructions. The guarantee is limited
to the repair or replacement of any defective or faulty item.
Proof of purchase must be retained.
• Hozelock extended guarantee covers the bottle and pump
mechanism only. It specifically excludes all O-rings & seals.
These have a 12-month guarantee, are wearing parts and are
available as spares from the retailer or from Hozelock direct.
Contact Details
Hozelock Limited
Midpoint Park, Birmingham. B76 1AB
Tel : +44 (0) 121 313 1122
Internet : www.hozelock.com
Email : info@hozelock.com
Dépistage des pannes
Issue
Problem
Weak or
Sprayer will not
no spray
pressurise
Obstruction
Distorted
Obstruction
Spray
Leaks
Build up of sediment
or foreign matter on
sealing surfaces
Worn or damaged
O-rings/Washers
Solution
Ensure all connections are
tight
Check O-rings and seals are
lubricated and show no signs
of wear or damage – replace
if required (see notes G, I & J)
There could be a blockage in
the nozzle, or the trigger or
the outlet tube
There could be a blockage in
the nozzle
Check O-rings and seals are
free from dirt – Clean or
replace if required
Check O-rings and seals are
free from wear or damage –
replace if required
