CONTROL PANEL AND KEYPAD

EN
A.
4 5
1
STOP
2
3
B.
12
13
C.
15 16
BACK
RESET
23
22
6
6 7
READY
Main Menu
ID: M1

Quick Setup

( 17 )
Monitor
( 5 )
Parameters
( 12 )
9 11
14
17 19
OK
21
A The graphical display
1 The location field
8
2 An activated group or item
The number of items in the group in
3
question
I/O
4 The first status field: STOP/RUN
5 The rotation direction
The second status field: READY/NOT
6
READY/FAULT
7 The alarm field
8 The control place
B The text display
9 The indicators of status
10 The indicators of alarm and fault
11 The name of the group or item
12 The current location in the menu
13 The indicators of the rotation direction
14 The indicators of the control place
C The buttons of the keypad
10
15 The BACK/RESET button
16 The OK button
17 The arrow button UP
18 The FUNCT button
19 The arrow button RIGHT
20 The START button
21 The arrow button DOWN
22 The STOP button
23 The arrow button LEFT
FUNCT (18)
Use it to change the rotation direction of
the motor, access the control page, and
change the control place.
18
Changing the control place:
1.
FUNCT
FUNCT
2.
3.
OK
4.
5.
OK
20
'Local/Remote'
'Local' or 'Remote'
