To install the projector on the projector wall mount
1
Attach the mounting plate to the projector using M4 × 12mm fasteners (4).
2
Install the projector on the Projector Wall Mount.
Slide the mounting plate with projector attached onto the setting plate. Secure the mounting
plate with M5 × 10 mm fasteners (4), as shown below.
3
Connect the power cable and other cables to the projector.
10
GB
Installation Procedures
M4 × 12mm
Fastener (4)
M5 × 10mm
Fastener (4)
Computer Cables
Power cord
