Projection Distance Table
VPL-SW535C/SW525C/SW535/SW525
Screen Size
Diagonal D Width × Height
70 inch 1.51 × 0.94
(1.78 m) (59 × 37)
80 inch 1.72 × 1.08
(2.03 m) (68 × 42)
90 inch 1.94 × 1.21
(2.29 m) (76 × 48)
100 inch 2.15 × 1.35
(2.54 m) (85 × 53)
130 inch 2.80 × 1.75
(3.30 m) (110 × 69)
VPL-SX535
Screen Size
Diagonal D Width × Height
60 inch 1.22 × 0.91
(1.52 m) (48 × 36)
70 inch 1.42 × 1.07
(1.78 m) (56 × 42)
80 inch 1.63 × 1.22
(2.03 m) (64 × 48)
90 inch 1.83 × 1.37
(2.29 m) (72 × 54)
110 inch 2.24 × 1.68
(2.79 m) (88 × 66)
Projection Distance (Y-X)
0.284-0.296
(11 1/4-11 5/8)
0.344-0.358
(13 5/8-14)
0.403-0.419
(15 7/8-16 1/2)
0.462-0.480
(18 1/4-18 7/8)
0.640-0.664
(25 1/4-26 1/8)
Projection Distance (Y-X)
0.293-0.305
(11 5/8-12)
0.364-0.377
(14 3/8-14 3/4)
0.434-0.450
(17 1/8-17 5/8)
0.505-0.523
(19 7/8-20 1/2)
0.646-0.668
(25 1/2-26 1/4)
Height B from wall
plate center to edge of
screen
0.328
(13)
0.349
(13 3/4)
0.369
(14 5/8)
0.390
(15 3/8)
0.452
(17 7/8)
Unit: m (inches)
Height B from wall
plate center to edge of
screen
0.353
(14)
0.382
(15 1/8)
0.410
(16 1/4)
0.439
(17 3/8)
0.495
(19 1/2)
Unit: m (inches)
Checking the Installation Position
7
