3.1. Maximum input values
Function
A AC, D CA
V DC, V AC
Resistance, diode, continuity test,
frequency, work cycle, capacity
Temperature (° C/° F)
4. Specifications
4.1. DC Volts
Ranges Resolution
400mV 100 µV
4 V 1 mV
40 V 10 mV
400 V 100 mV
600 V 1 V
Overload protection: 600V AC/DC
Input Impedance: 10 MΩ
4.2. AC Volts
Range Resolution
400 mV 100 µV
4 V 1 mV
40 V 10 mV
400 V 100 mV
600 V 1 V
Overload protection: 600 V AC/DC
Frequency range: 50/60 Hz
Input Impedance: 10 MΩ
4.3. DC Current
Range Resolution
40 A 10 mA
400 A 100 mA
Overload protection: 400 A
Max. Input
400 A
600 V DC/AC
250 V DC/AC
250 V DC/AC
Accuracy
± 0,8% rdg. + 2 dgt.
± 1,5% rdg. + 2 dgt.
± 2,0% rdg. + 2 dgt.
Accuracy
± 1,0% rdg. + 10 dgt.
± 1,5% rdg. + 5 dgt.
± 2,0% rdg. + 5 dgt.
Accuracy
± 2,5% rdg. + 5 dgt.
± 2,8% rdg. + 5 dgt.
