English
Index / pages
1. GROUP I (about 9 to 18 kg) ................................................................................................................................S. 16
1.1. Using HEYNER® MultiProtect ERGO 3D-SP as a child car seat ................................................S. 16
1.2. Connecting the backrest to the booster seat ..........................................................................................S. 17
1.3. Adjusting HEYNER® MultiProtect ERGO 3D-SP to your child's size .......................................S. 18
1.4. Installing HEYNER® MultiProtect ERGO 3D-SP into your car ..................................................S. 20
1.5. Securing the child into HEYNER® MultiProtect ERGO 3D-SP ...................................................S. 23
2. GROUP II+III (about 15 to 36 kg) .......................................................................................................................S. 23
2.1. Using HEYNER® MultiProtect ERGO 3D-SP without harness belts .......................................S. 23
3. Care instructions ..................................................................................................................................................S. 26
4. Important notices ................................................................................................................................................S. 27
5. Some final hints ....................................................................................................................................................S. 29
Operating Instructions J Shoulder belt slots
J3 for children up to 3 years
(children about 14 - 18 kg)
A Headrest
J2 for children up to 2 years
B Backrest
(children about 12 - 14 kg)
C Booster
J1 for children up to 1.5 years
D Harness belt
(children about 9 - 12 kg)
D1 Shoulder belt
K Belt anchorage
D2 Waist belt
L Fixation lugs for
D3 Harness central belt
three-point-vehicle-belt
D4 Buckle belt
M Belt clip
E Buckle latches
N Diagonal belt of the
F Belt buckle
three-point-vehicle-belt
G Belt hook
O Lap belt of the
H Belt adjuster
three-point-vehicle-belt
I Belt end element
15
1. GROUP I (about 9 to 18 kg)
1.1. Using HEYNER® MultiProtect ERGO 3D-SP as a child car seat
You have purchased HEYNER® MultiProtect ERGO 3D-SP car seat for your child. We thank
you for your trust. Please take enough time for the correct handling of your car. Please note
that the optimum safety characteristics and comfort can only be achieved, if the seat is used
properly according to instructions. Please keep instructions always
with the seat for further information.
HEYNER® MultiProtect ERGO 3D-SP child seat is approved in accordance to the European
standard for child restraint systems ECE R44/04. If you make any changes on the seat, the
approval looses its validity.
IMPORTANT: HEYNER® MultiProtect ERGO 3D-SP is only approved for the installation type
P Buckle latch of the
with the three-point seat belt (universal). It is not allowed to use it, in case there is only a
three-point-vehicle-belt
two-point seat belt. The belt has to be approved in accordance to the ECE R 16
Q Belt buckle of the
(or to similar norms). This is for example recognisable by the "E", "e" on the testing tag which
three-point-vehicle-belt
R Connecting hooks is on the belt. If you use the seat on the passenger seat, please slide it as far back
S Connecting holes as possible and note the hints in the vehicle manual.
T Backrest cover velcro
U Booster cover velcro
ATTENTION:The approval will be invalid as soon as you make changes on the child car seat.
V Backrest cover button
Changes must only be made by the manufacturer. HEYNER® MultiProtect ERGO 3D-SP must
W Shoulder pad connector
only be used to secure your child in the vehicle. Never use the seat as toy nor as seating
X Belt anchorage of waist belt
accommodation. Never secure your child nor the seat with a two-point seat belt.
Y Belt anchorage of
If you only secure your child with a two-point seat belt, it can be seriously injured or even die.
buckle belt
Only to be assembled by adults!
Z Head rest de-block lever
English
