MD 9231 Industrial TRMS AC/DC Current Clamp Meter

Maintenance

5 MAINTENANCE
WARNING
To avoid electrical shock, disconnect the meter from any circuit, remove the test leads
from the input jacks and turn OFF the meter before opening the case. Do not operate with
open case.
Trouble Shooting
If the instrument fails to operate, check batteries and test leads etc., and replace as
necessary. Double check operating procedure as described in this user's manual.
If the instrument voltage-resistance input terminal has subjected to high voltage transient
(caused by lightning or switching surge to the system under test) by accident or abnormal
conditions of operation, the protective impedance components in series might be blown
off (become high impedance) like open fuses to protect the user and the instrument. Most
measuring functions through this terminal might then be open circuit. Such components
should only be replaced by qualified technician. Refer to the LIMITED WARRANTY
section for obtaining warranty or repairing service.
Accuracy and Calibration
Accuracy is specified for a period of one year after calibration. Periodic calibration at
intervals of one year is recommended to maintain meter accuracy. Refer to the LIMITED
WARRANTY section for obtaining calibration, repairing or warranty service.
Cleaning and Storage
Periodically wipe the case with a damp cloth and mild detergent; do not use abrasives or
solvents. If the meter is not to be used for periods of longer than 60 days, remove the
batteries and store them separately.
Battery replacement
The meter uses standard 1.5V AA Size (IEC R6) battery X 2.
Loosen the 2 captive screws from the battery cover case. Lift the battery cover case.
Replace the batteries. Replace battery cover case. Re-fasten the screws.
