Example 2: If a tyre is tested for 1 hour at a speed of
180 km/h, the total distance travelled is 180 km.
Number at the
Instantaneous
value display
Hint: Since one value is transferred each second, 3600 val-
ues are totalled in an hour.
In order to make full use of the display range of the totalizer,
the expected result will be displayed with two decimal digits.
The 180.00 km corresponds to a number of 18 000 at the
output of the totalizer.
The total scaling of
648 000.0 : 18 000 = 0.027777...
Is carried out by setting the factor = 2.7778 (rounded) and the
scale = 0.01.
Number at the
Totalizer
display
4.4.2.1 Setting the decimal point for the totalizer
Menu
The decimal point has only a visual effect in the display. It
does not influence the result.
input of
totalizer
180.0 x
output of
totalizer
18 000
Selection Enter
(max. 3 decimal places)
Number of values
3 600
Total scale
0.027778
Unscaled result
in the totalizer
648 000.0
Unscaled result
in the totalizer
x 648 000.0
