4

Parameter Setup

The parameters have to be setup before putting the unit into
operation. It is recommended to set them up before mounting.
– Input parameter
The parameters of the characteristic curve of the unit must
be setup depending on the sensor used.
– Characteristic curve
The correspondence between the input signal and the
displayed value is given by the characteristic curve. The
characteristic curve is setup by entering pairs of values.
– Totalizer
The decimal point, the factor for the measuring unit, and
the scale for displaying the total value calculated by the
unit must be setup.
– Mains hum filter
The local mains frequency will be selected.
4.1

Setup Mode

Start the setup mode:
– Hold keys
– Connect unit to the power supply.
The display shows
– Release keys.
8
.
.
