4.3.2 Define first knee point
Set input value corresponding to the beginning of the char-
acteristic curve in the respective units (e.g. V, mA).
Menu
Set display value for the starting point of the curve.
Menu
4.3.3 Define second knee point
Set input value.
Menu
Set display value.
Menu
4.3.4 Define further knee points
Additional knee points will be requested only when in section
4.3.1 14 more than 2 knee points are defined.
Selection Enter
Select digit.
Set digit.
Selection Enter
Select digit.
Set digit.
Selection Enter
Selection Enter
Example: –5.000
Example: –250.0
Example: 02.000
Example: 300.0
