Electrical connection
Device socket 1
Pin RS‐485
1 GND
2 -
3 RA
4 Trigger input
5 RB
6 TB
7 TA
8 U
B1
1)
For digital load cells, HBM recommends two cable types, 1-KAB165 or 1-KAB173, depending on
the application. Detailed information about these cables is available in data sheet B3643, which
can be found under "Product Data Sheet & Literature" on our website
2)
The trigger input is referenced to the GND of pin 1.
16
FIT7A pin assignment - type S
CANopen/
DeviceNet
GND
-
CAN High IN
2)
Trigger input
CAN Low IN
CAN Low OUT
CAN High OUT
U
B1
A3924-1.1 HBM: public
Wiring code for
1-KAB165
White
Brown
Green
2)
Yellow
Gray
Pink
Blue
Red
Wiring code for
1)
1-KAB173
White
Brown
Green
Yellow
Gray
Black
Blue
Red
http://www.hbm.com/fit7a
1)
®
FIT 7A
