An automatic charger designed to charge both normal and
maintenance-free 12 V starter batteries (lead-acid
accumulators) as well as AGM / lead-acid (MF, VRLA)
batteries used in cars.
This charger is also suitable for charging 12.8V LiFePO4
lithium batteries.
The charger is controlled by a microprocessor which,
when the accumulator is charged, switches the charger
automatically into a charged mode where the
microprocessor maintains targeted charging without
overcharging or damaging the accumulator.
Along with battery charging, it also offers:
SUPPLY – power supply of the vehicle with battery
ź
removed to keep on-board systems running
RECONDITION – systematic pulse strikes to restore
ź
the battery to good condition
BATTERY TEST – for quick evaluation of the condition
ź
of the car battery and evaluation of the charging of the
car (an alternator).
In order to ensure safe and proper use of the charger, this
manual must be thoroughly studied before use.
Safety instructions
Only intended for charging lead-acid accumulators.
ź
Always connect the accumulator first and then the
ź
charger into the 230V mains.
Explosive gases – do not use open fire while handling.
ź
Provide adequate ventilation during charging.
ź
Do not smoke, drink or eat while charging.
ź
For indoor use only.
ź
Protect from moisture. Protect from children.
ź
Do not open the charger. Do not shorten cables.
ź
If the charger body or cable is damaged, the product
ź
cannot be used.
Pay attention to the safety of use during use – risk of
ź
electric shock.
When handling batteries, we recommend the use of
ź
protective glasses, gloves and protective clothing.
In case of contact with the electrolyte, immediately
ź
wash the affected area with plenty of water, if
necessary seek medical attention.
Never short the pole terminals.
ź
Check the functionality of the device before each use.
ź
This device must not be used by persons (including
ź
children) with limited physical, sensory or psychic
abilities or persons with a lack of experience in
operating these devices or with a lack of necessary
knowledge. These persons can only use the device
under the supervision of an experienced person, who
ensure their safety or instruct them how to use the
device. Ensure that children do not play with the
device.
The accumulator on the water (e.g. in a dinghy or a
ź
boat) must be dismantled and it is essential to charge it
on land!
4
ORIGINAL OPERATING INSTRUCTIONS
Car batteries that have not been used for a long time
ź
may not work properly due to spontaneous discharge
or sulphation. These batteries cannot be charged.
The battery charger must not be used as a
ź
replacement for a power supply.
When charging the battery, never start the vehicle
ź
engine.
We recommend removing the battery from the vehicle
ź
before charging. Refer to the vehicle documentation for
the procedure.
This device is not designed for trade, craft or industrial
ź
use. We do not assume any warranty when this device
is used in a such way.
Please observe the operating instructions for the car,
ź
radio, navigation system, etc.
One or more fuses are integrated into the charger. If
ź
the fuse is damaged, replace it with a new one with the
same amount.
Device description
1) Function key
2) LED display
3) Charging cable black (-)
4) Charging cable red (+)
5) Power supply
Danger! The device and packaging material are not a toy!
Children must not play with plastic bags, foils and small
parts! Risk of swallowing and suffocation!
Instructions for charging:
For batteries with cell closures, remove the cell
ź
closures and check out the status of the battery
charging. If the electrolyte level is below the
recommended level, add distilled water.
For batteries without cell closures, carefully follow the
ź
manufacturer's charging instructions.
Make sure that the vehicle's ignition is switched off (if
ź
the accumulator is connected in the vehicle).
Connect the charger to the 230V mains.
ź
Hold the MODE button for 2 seconds to activate mode
ź
switching. To switch between modes, shortly press the
MODE button in the following order CHARGING –
SUPPLY – RECONDITION. Hold the mode button (2
seconds) to confirm the selected mode.
CHARGING mode – Charging the battery:
Press the MODE button repeatedly to select the type
ź
of accumulator charging – STD (standard), GEL (gel),
AGM or LFP (lithium LiFePO4).
Insert the positive clamp of the charger (red) to the
ź
positive (+) terminal of the accumulator.
Connect the negative clamp of the charger (black) to
ź
