Avr2 - Spannungsregelung (Avco) - MR Tapcon Beiblatt

Attribute
Name
LDCX
LDC
LDCZ
SptCtlVMax
SptCtlVMin
SptCtlV0
SptCtlWMax
SptCtlWMin
Tabelle 5: AVR1 Spannungsregler (ATCC )
Attribute Name
AVCO1
Common Logical Node Information
Mod
Beh
NamPlt
Controls
TapChg
Measured values
-
Status Information
Loc
Settings
-
Tabelle 6: AVR2 - Spannungsregelung (AVCO )
12 TAPCON®
Attribute Explanation
Type
ASG Line drop voltage due to line reac-
tance component (inductive behavi-
our of the cable)
SPG Line drop compensation. LDC is R
and X or Z model TRUE = R and X,
FALSE = Z. If compensation is
deactivated, value is set to TRUE
ASG Line drop voltage due to line total
impedance (percentage of nominal
voltage)
ASG Maximum voltage value for dyna-
mic setpoint control (TDSC)
ASG Minimum voltage value for dynamic
setpoint control (TDSC)
ASG Voltage value for dynamic setpoint
control at active power of 0 W
(TDSC)
ASG Maximum active power value for
dynamic setpoint control (TDSC)
ASG Minimum active power value for dy-
namic setpoint control (TDSC)
5.1.4

AVR2 - Spannungsregelung (AVCO)

Attribute Explanation
Type
- AVR2
INC Mode
ENS Behaviour
LPL Name plate
BSC Change Voltage
-
SPS Local operation
-
-
-
4077074/00 DE
5 Datenpunkte
M/O/E Remarks
O -
O -
O Unit: c
Multiplier: c
E Unit: V
Multiplier: none
E Unit: V
Multiplier: none
E Unit: V
Multiplier: none
E Unit: Watts
Multiplier: none
E Unit: Watts
Multiplier: none
M/O/E Remarks
- -
M status-only
M -
M -
M direct-with-nor-
mal-security
- -
M -
- -
Maschinenfabrik Reinhausen 2014
