MR Tapcon Beiblatt Seite 11

5 Datenpunkte
Attribute
Name
FuncMon
VInFail
MotDrv
SptCtlErr
TapPosDif
Settings
BndCtr
BndCtrV1
BndCtrV2
BndCtrV3
BndCtrV4
BndCtrV5
BndWid
CtlDlTms
BlkLV
LimLodA
TmDlChr
TapBlkR
TapBlkL
LDCR
Maschinenfabrik Reinhausen 2014
Attribute Explanation
Type
SPS Function monitoring
SPS Voltage input failure (e.g. missing
connection)
SPS Motor drive running
SPS Dynamic Setpoint Control error
(TDSC)
SPS Tap position difference
ASG Band center voltage (actual refe-
rence - can not be set)
ASG Band center voltage 1
ASG Band center voltage 2
ASG Band center voltage 3
ASG Band center voltage 4
ASG Band center voltage 5
ASG Band width voltage (as percent of
nominal voltage)
ASG Control intentional time delay T1 (in
seconds)
ASG Control voltage below which auto
Lower commands blocked (relative)
ASG Limit Load Current (LTC Block Lo-
ad Current, percentage)
SPG Time delay linear or inverse cha-
racteristic (0=lin., 1=inv.)
ING Tap position of Load Tap Changer
where automatic Raise commands
are blocked
ING Tap position of Load Tap Changer
where automatic Lower commands
are blocked
ASG Line drop voltage due to line resis-
tance component (ohmic behaviour
of the cable)
4077074/00 DE
M/O/E Remarks
E -
E -
E -
E -
E -
O Unit: V
Multiplier: none
E Unit: V
Multiplier: none
E Unit: V
Multiplier: none
E Unit: V
Multiplier: none
E Unit: V
Multiplier: none
E Unit: V
Multiplier: none
O Unit: c
Multiplier: c
E Unit: s
Multiplier: none
O Unit: c
Multiplier: c
O Unit: c
Multiplier: c
O -
O -
O -
O -
