Avr1 - Spannungsregler (Atcc) - MR Tapcon Beiblatt

5 Datenpunkte
Attribute
Name
ATCC1
Common Logical Node Information
Mod
Beh
NamPlt
Controls
TapChg
ParOp
LTCBlk
Auto
BndCtrAct1
BndCtrAct2
BndCtrAct3
BndCtrAct4
BndCtrAct5
CircASel
MasterSel
FollowerSel
Measured values
CtlV
LodA
CircA
PhAng
Maschinenfabrik Reinhausen 2014
5.1.3

AVR1 - Spannungsregler (ATCC)

Attribute Explanation
Type
AVR1
INC Mode
ENS Behaviour
LPL Name plate
BSC Change Tap Position
SPC Parallel/Independent
SPC Block Automatic Control
SPC Automatic Manual
SPC Band center voltage (desired value)
1 active
SPC Band center voltage (desired value)
2 active
SPC Band center voltage (desired value)
3 active
SPC Band center voltage (desired value)
4 active
SPC Band center voltage (desired value)
5 active
SPC Circulating current selection activa-
tion (parallel control)
SPC Master mode selection activati-
on(parallel control)
SPC Follower mode selection activati-
on(parallel control)
MV Control Voltage
MV Load Current (transformer secon-
dary current)
MV Circulating Current (reactive)
MV Phase Angle of LodA relative to
CtlV
4077074/00 DE
M/O/E Remarks
- -
M status-only
M -
M -
C direct-with-nor-
mal-security
M direct-with-nor-
mal-security
O direct-with-nor-
mal-security
O direct-with-nor-
mal-security
E direct-with-nor-
mal-security
E direct-with-nor-
mal-security
E direct-with-nor-
mal-security
E direct-with-nor-
mal-security
E direct-with-nor-
mal-security
E direct-with-nor-
mal-security
E direct-with-nor-
mal-security
E direct-with-nor-
mal-security
M Unit: V
Multiplier: none
O Unit: A
Multiplier: none
O Unit: A
Multiplier: none
O Unit: deg
Multiplier: none
TAPCON® 9
