SYSTEM LAY-OUT

❷
❺
❶
1 - KING FAST operator
2 - Tuned aerial
3 - Flashing lamp
4 - Key selector
5 - Photoelectric cells (external)
1
2
1
2 W
3 U
3
❶ ❺ ❹
V
Measurements in mm
T
ECHNICAL FEATURES
KING FAST is a irreversible operator, suitable for opening gates
with a leaf length of up to 2,5 metres (Fig. 1).
❸
The KING FAST operator use mechanical stoppers, thus
avoiding the need for electrical limit switches.
On reaching the travel limit, the motor continues to operate for a
few seconds, until the timer of the control unit cuts in.
❹
TECHNICAL
DATA
Max. leaf length
Max. leaf weight
Max. travel
Average opening time
Operating speed
Thrust force
EEC Power supply
Motor capacity
Power absorbed
Capacitor
Normative cycles
Daily operations suggested
Service
Guaranteed consecutive cycles
Grease
Weight of electroreducer
Noise
Volume
Operating Temperature
1
Protection
** With incorporated mechanical stop that cuts in during opening. - If
the mechanical stop is used during closing (optional), the maximum
travel is reduced by 50 mm.
25
25
KING FAST
m 2,5
kg 400
mm 345**
s. 7÷13
m/s 0,024 (50Hz) 0,028 (60Hz)
N 2000
230V~50Hz 220V~60Hz
W 240 213
A 1,35 1,3
mF
8
n° 45 - 11s/2s 98 - 11s/2s
n° 150
60%
n° 90/11s
Lhitgrease EP/GR2
kg 10
db <70
m 0,0184
3
°C -10 ÷ +55°C
IP 44
2
G
B
