SYSTEM LAY-OUT

TECHNICAL FEATURES

MAGIC is a reversible operator with a mechanical cluth to adjust the force of the motor ad its
reversibility (more force you set, less reversible it is).
The operator comes complete with a mechanical limit switch group, a transmission lever,
and a trafficable cover.
MAGIC is supplied as a compact unit complete with a steel foundation box (41x25x17h cm).
The profile of the box is recessed to facilitate installation.
MAGIC functions as a load-bearing centre hinge, designed in such a way that the motor can
be removed for servicing purposes without taking down the gate.
MAGIC drive is reversible, and therefore requires no release mechanism.
MAGIC will comfortably operate gates and doors up to 350 kg in weight and 2.5 metres in
length, with an opening time of 20 seconds for the 105° version and 40 seconds for the 180°
version (in compliance with current standards).
❷
❺
❶
❹
❶
❶
MAGIC operator
❷
Radio antenna
❸
Blinker
❹
Photoelectric cells (external)
❺
Photoelectric cells (internal)
❺
❻
Key selector
Ø65 - 2,6"
Ø35 - 1,4"
❸
❶
❹
❶
1,96"
2,3"
4"
9,8"
Measurements in mm/inch
MAGIC 105° version (fig 3): this has a system controlling the speed of the opening and
closing movements (opening movement initially slow, then fast; closing movement initially
fast, then slow immediately before shutting).
MAGIC 180° version (fig 4): installing this version, a gate can be rotated through 180° if
the drive shaft is coaxially aligned with the hinge centre, or through 150° with the drive shaft
offset from the centre of rotation by up to 4.5 cm.

TECHNICAL DATA

Max. leaf length
Max. leaf weight
❻
Average opening time
Max torque
EEC Power supply
❺
Motor capacity
Power absorbed
Capacitor
EEC Power supply
Motor capacity
Power absorbed
❻
Capacitor
Normative cycles
Daily operations suggested
Service
Guaranteed consecutive cycles
Grease
Weight of electroreducer
Noise
Volume
Operating Temperature
❺
Protection
1
3,4"
16,1"
21
MAGIC MAGIC
105° 180°
m 2,5
kg 350
s 20
Nm 250
230V~ 50/60Hz
W 190
A 0,8
µF 6,3
120V~ 60Hz
W 200
A 1,8
µF 25
n° 18 - 20s/2s 10 - 33s/2s
n° 80
% 50
n° 33/20s 16/40s
SHELL OMALA S2 G100
kg 21
db <70
m 0,020
3
°C -10 ÷ +55
IP 677
Ø35 - 1,4"
1,96"
Ø65 - 2,6"
2,3"
4"
9,8"
G
B
40
2
