Introduction; Technical Data - Lukas AMIN 20-030 GH Bedienungsanleitung

1. Introduction

The AMIN 20-030 GH is a pneumatic power tool reflecting state-of-the-art technology.
It is driven by a vane air motor using compressed air.
The integral speed controller keeps the rotation at a constant speed.
With this power tool both tungsten carbide burrs and mounted points can be used
economically.
The vibration and sound values specified in the technical data were measured
according to EN 28662-1 and EN ISO 8662-13 as well as prEN ISO 15744.

2. Technical Data

Type:
max. RPM:
Service pressure:
Nomials hose diameter:
Weight:
Dimensions:
Output:
Air Consumption:
Noise levell:
Stand: 25.01.2013
Prior to using the power tool you should become familiar with
the operation instructions.
The power tool must not be commissioned before the safety
information for the operator has been read.
straight die grinder with lever valve
-1
20.000 min - 10%
0,63 MPa
8 mm
approx.. 0,72 kg
ca. ∅ 34,5 x 175 mm
0,3 KW
approx. 0,53 m³/min.
81 dB(A) max.
12 - AMIN 20-030 GH -
