8. Spare Part List

Pos. Description
1 IDENTIFICATION PLATE
11 HEAD UNIT
12 HOUSING
13 O-RING SEALING 27 x 1,5
20 DRIVE UNIT
201 STATOR
202 ROTOR
203 VANE SET
204 FACE PLATE OUTLET
205 FACE PLATE INLET
206 SPACER
207 SPINDLE
208 SPINDLE NUT
209 BUSH
210 SCREW
211 O-RING SEALING 15 x 1,5
212 REGULATOR UNIT
2121 BALL CARRIER
REGULATOR
2122
2123 SCREW
2124 PRESSURE SPRING
2125 BALL 4,0
2126 PIN 1 x 8 DIN 6325
213 BALL BEARING
214 BALL BEARING
215 PIN 1,5 x 7,8
216 O-RING SEALING 10 x 1,5
21 COLLET 6,00 mm
30 VALVE UNIT
301 VALVE HOUSING
302 LEVER
303 SCREW
304 VALVE
305 VALVE SPRING
Stand: 25.01.2013 Stand: 25.01.2013
LE-Item-Nr.
A874300904XXX
A872400104053
A871700100298
A87350127015
A874800012103
A874900378087
A873800201172
A872900378109
A875100202085
A875100202084
A873500600102
A875500302195
A873100501118
A872100615040
A875700612106
A87350115015
A873400012078
A872600206010
A873400205027
A875700612077
A871500605045
A872500040052
A8750000108
A87280161900
A8728000628
A87500000107
A87350110015
A874700502086
A875301014XXX
A875302406XXX
A872000403058
A87570061201301
A875300407030
A87150060502402
