1. Introduction

The AM 07/100 is a pneumatic power tool reflecting state-of-the-art technology.
It is driven by a vane air motor using compressed air.
The integral speed controller keeps the rotation at a constant speed.
This power tool is qualified exclusively for manual radial grinding with conical grinding
wheels type 4 according to DIN ISO 603-12 with a maximum diameter of 125 mm
and a minimum permissible operating speed of 50 m/s.
The vibration and sound values specified in the technical data were measured
according to EN 28662-1 and EN ISO 8662-13 as well as prEN ISO 15744.

2. Technical Data

Type:
max. RPM:
Service pressure:
Nomials hose diameter:
Weight:
Dimensions:
Output:
Air Consumption:
Noise levell:
Stand: 27.10.2008
Prior to using the power tool you should become familiar with
the operation instructions.
The power tool must not be commissioned before the safety
information for the operator has been read.
straight die grinder with lever valve
7.600 min -1 - 10%
0,63 MPa
13 mm
approx.. 3,8 kg
ca. ∅ 74 x 530 mm
1,5 KW
approx. 1,55 m³/min.
85 dB(A) max.
12 - AM 07/100 GH -
