Connecting the Telewarm

Connect Telewarm G1-D into the terminals 3 and 4 on the DD2+
wall plate (Picture 21).
To learn more about connecting the Telewarm on electric and
telephone network see User manual for Telewarm.

Connecting the auxiliary temperature sensor

Always connect the auxiliary tem-
perature sensor into the connector
terminals 3 and 4 on wall DD2+
plate (Picture 21). Set the parame-
ters for this sensor in service group
S1. Telewarm for remote activa-
tion, can also be connected in the
same terminals.
On the DD2+ can be connected only MURATA type sensors. This
sensors are:
- outdoor sensor AF/M,
- room sensor PS10/M,
- immersion sensor TF/M.
INSTALLATION MANUAL
Picture 21
