Anschließen des Cisco IP-Telefons
DC-Adapteranschluss (DC48V)
1
Netzteil mit AC-Adapterstecker
2
Stromkabel mit Netzstecker
3
Netzwerkanschluss (10/100 SW)
4
Cisco IP-Telefonmodelle 7960 und 7940 - Benutzerhandbuch
1-4
Abbildung 1-1
Cisco IP-Telefonkabelanschlüsse
1
RS232
10/100 SW
+
DC48V
2
3
4
Kapitel 1
10/100 PC
6
5
Zugangsanschluss (10/100 PC)
5
Höreranschluss
6
Kopfhöreranschluss
7
Einführung in das Cisco IP-Telefon
7
78-13693-02
