Miscellaneous Settings

MENU
SETTING HSIC
The default password is: UP - DOWN - UP - DOWN - ENTER
UPLOAD: sends the user programs to connected slave fixtures.
RESET: sets all editable settings back to factory default.
DIMMER: controls different dimming speeds to simulate a halogen bulb (OFF/DIM1/DIM2/DIM3/
DIM4).
DMX ERROR: sets how the fixture responses if DMX-signal gets lost. Set SAVE to hold the last
received value or BLACK for blackout.
PWM_RATE: gives the user the possibility to adjust the PWM frequency of the leds (600HZ/1200HZ/
2000HZ/4000HZ/6000HZ/25000HZ).
FULL POWER CCT: sets the colour temperature at maximum output. 2700K/3200K/4200K and
NORMAL can be set.
COLOR: in this submenu a colour calibration is selected or deactivated. When RGBTOW is selected,
the maximum brightness values at DMX = 255 are limited to the values set in CCT\RGBTOW.
When UC is selected the Uniform-Colour factory calibration is used, which adjusts devices of
different generations. If the value is set OFF, the calibration is deactivated and the device reaches
the maximum brightness.
FANS: SLOW/NORMAL/FAST/AUTO regulates the fan performance balance.
MODE SETTING: sets whether the fixture is a master and sends data to other fixtures (MASTER),
or not (SELF).
UPLOAD
****
RESET
DIMMER
DMX ERROR
PWM_RATE
POWER CCT
COLOR
FANS
MODE SETTING
E-30
SEND
****
RESET
****
DIM4
DIM3
DIM2
DIM1
OFF
SAVE
BLACK
600HZ
1200HZ
2000HZ
4000HZ
6000HZ
25000HZ
2700K
3200K
4200K
NORMAL
OFF
RGBTOW
UC
SLOW
NORMAL
FAST
AUTO
SELF
MASTER
