RUN MODE
3.5
Enter the RUN MODE mode to set working mode.
DMX MODE is for using the DMX512 controller to control the
fixtures.
SLAVE MODE is for Master-Slave operation.
MENÜ MENU
RUN MODE
DMX PERSONALITY
3.6
Enter the PERSONALITY mode to select DMX mode: HSIC,
SIMPLE, SDO, COLOR 8BIT, COLOR 16BIT.
MENÜ MENU
PERSONALITY
3.7

SPECIAL SETTINGS

SETTING...this menu allows the user to adjust key operation set-
tings for this fixture.
Select UPLOAD to upload the custom programs from the current
MASTER unit to the SLAVE units.
In order to reset custom modes to default values select RESET.
Note: UC\RGBW\CALIB.C can´t reset
COLOR is for activate/unactivate the color calibration functions.
When RGBW is selected, on RGB = 255,255,255, the color is
displayed as calibrated in CALIB.C -- RGBW. When COLOR is set
OFF, on RGB = 255,255,255, the RGBvalues are not adjusted and
the output is most powerful. When UC is selected, the RGB output
are adjusted to a standard preset universal color which balances
fixtures from different generations.
NOTE:[COLOR WORK ONLY WHEN CHOOSE NORMAL AT FULL
POWER CCT.
Select DIM1, DIM2, DIM3 or DIM4 for different dimming speeds
(DIM4 is the slowest dimming speed).
DMX
SLAVE
HSIC
SIMPLE
SDO
COLOR 8 BIT
COLOR 16 BIT
