Activate Password Protection
MENU
KEY
PERSON
In the menu KEY the password protection of the fixture is activated or deactivated. If set ON the
fixture is password protected when started. 30 seconds after the last setting the menu is locked
again. To be able to make changes in the menu the password UP - DOWN - UP - DOWN - ENTER
needs to be typed in.
Calibration and Whiteadjustment
MENU
HSIC CCT
In the menu CCT, submenu CCT the preset colour temperatures for the white values are stored.
These can be adjustest via X FINE and Y FINE (+/-200).
Info Menu
MENU
HSIC INFO
In the info menu (INFO), submenu VERSION the currently installed firmware version is shown. In the
submenu RDM, submenu UID the RMD-ID of the fixture and in the submenu LABEL the model name
of the fixture can be found.
HSIC ON
HSIC OFF
1800K
****
2200K
2700K
3000K
3200K
3500K
4000K
4200K
4500K
5600K
6000K
6500K
7200K
8000K
VERSION VXX
RDM
UID
LABEL
E-31
X FINE +/-200
+/-200
Y FINE
35xxxxxxxxxxxx
PROPAR X3 COB
