Setting DMX-Address
MENU
PERSON ADDRESS
The DMX start address of the fixture is set in the menu ADDRESS. This is retained even when
changing the personality.
Setting DMX-Personality
MENU
PERSONALITY PERSON
The personality is set in the menu PERSONALITY. There are six different modes which can be
chosen: BASIC (3 channels), CLR (6 channels), HSIC (7 channels), SSP (10 channels), TOUR
(13 channels) and TR16 (20 channels).
Edit Static Colours
MENU
PERSON STATIC
Static colours for stand-alone operation are set in STATIC. These are mixed using the DMX value
scale 0-255 for RED, GREEN, BLUE, AMBER, LIME and CYAN, as well as the STROBE value
0-25Hz.
Preset Static Colours
MENU
PRESET COLOR PERSON
In the menu PRESET COLOR some preset RAL- (R) and LEE-colours (L) can be chosen.
001 - 512 HSIC
BASIC
CLR
HSIC
SSP
TOUR
Tr16
0-255
HSIC RED
GREEN 0-255
0-255
BLUE
AMBER 0-255
0-255
LIME
CYAN 0-255
STROBE 0-25
L106
R05
L194
R54
L019
R08
R89
R86
L213
R377
R80
L202
L328
R3314
L101
L768
E-28
