3.4
Statischer Betrieb
MENU
STAT
DIM
ZOOM
Hinweis: Wenn das Gerät auf den Modus Master geschaltet ist, werden die
statischen Einstellungen automatisch an alle gleichen Geräte die durch eine
Datenverbindung verbunden sind weitergegeben.
Wenn das Gerät DMX-Daten empfängt wechselt es nach 2 Minuten zurück
in das Hauptmenü.
3.5
RUN Modi
MENU
RUN
DMX
SLAV
Es kann zwischen dem RUN-Modus DMX für Betrieb via DMX-512 oder Slave
für Master-Slave Betrieb gewählt werden.
3.6
DMX Adresse
MENU
ADDR
D.(001-512)
Die benötigte Startadresse einstellen für DMX-512 Betrieb.
3.7 Motor reset
MENU
MOTR
NO
YES
Im Menü MOTR kann der Stellmotor für den Zoom reseted werden
(0~100)
(0~100)
D 06
3.8 SPECIAL SETTINGS
MENU
SET
KEY
DIMX
CURV
REST
PERS
SLCK
DERR
ZOOM
PERF
MCON
¡[SET]...this menu allows the user to adjust key operation settings for this fixture.
[KEY]...select [ON] for automatic lock-out. Password to re-enter the display is <UP>
+ <DOWN> + <UP> + <DOWN>.
¡
Select [DIM1], [DIM2], [DIM3] or [DIM4] for different dimming speeds. ([DIM4]is the slowest
dimming speed)
¡[CURV] allows the user to adjust the shape of the dimming curve. See the CURV chart to
Understand more about actual dimming curves.
¡ In order to reset custom modes to default values select REST .
¡[PERS]...this setting allows the user to select the DMX personality of the fixture. Refer to
DMX personality charts for specific details.
¡[SLCK] is used to lock the settings menu. When [SLCK] is set to [ON] then user must insert
passcode (UP+DOWN+UP+DOWN) in order to access the settings menu.
¡ DERR
[
] C
hoose Save in order to save the last DMX data incase of DMX signal error.
[
]
Choose Black in order to blackout in case of DMX signal error.
[
]
¡<ZOOM> is for setting zoom, press UP/DOWN to select. <BASE> is standard setting;
<POS1> is zoom setting 1; <POS2> is zoom setting 2. Press MENU to get back, and the
Setting is saved automatically.
¡[PERF]this setting allows the user to select the performance characteristics of the fixture.
¡[MCON]...this function allows the user to select whether the fixture will send DMX data to
other fixtures during stand-alone operation. The [MAST] setting allows data to be sent to
Other fixtures. The [SELF] setting is default and will not send DMX data to other fixtures.
OFF
ON
OFF
DIM1
DIM2
DIM3
DIM4
OFF
CV1
CV2
CV3
****
REST
OK
UNO
DOS
STD.P
OFF
ON
SAVE
BLAK
BASE
POS1
POS2
LIVE
STDO
POWR
SELF
MAST
[
]
E 07
